WyreStorm MX-0808-H2A-MK2 video switch HDMI
Beskrivelse
Beskrivelse
Login as partner to view prices
The MX-0808-H2A-MK2 is a welcome refresh to the powerful line of H2A pure HDMI switchers. The MK2 is familiar on the surface but has a host of improvements and added features. To start, the HDMI outputs now feature 4K > 1080p downscalers promoting easier integration of mixed resolution displays into a single system. The HDMI outputs also now support Audio Return Channel from smart TVs to bring audio from apps like Netflix, Prime Video, Hulu, etc.…to an external audio system. Speaking of audio, the analog audio outputs have been updated to balanced connections to ensure there is no loss in fidelity or interference.
SCALERS
Each of the 8 outputs on the MK2 feature down scalers, allowing support for mixed resolution distribution of HDMI content to 4K and 1080p display simultaneously.
AUDIO DE-EMBED
Featuring balanced analog and a digital S/PDIF, easily de-embed audio from either the HDMI inputs or ARC to a secondary audio distribution system without the need for external adapters or converters.
ARC SUPPORT
All 8 HDMI outputs support Audio Return Channel from smart TVs apps like Netflix, Prime Video, Hulu, etc.….The ARC audio can then be sent through either the digital S/PDIF or balanced analog outputs to an AVR or stereo amp.
2160P 4:4:4
As a standard requirement with the latest WyreStorm products, the MK2 supports the latest video formats including 4K HDR and Dolby Vision content all in uncompressed HDMI glory.
Specifikationer
Specifikationer
| Ports & interfaces | |
|---|---|
| RS-232 ports | 1 |
| 3.5 mm (1/8-inch) in | Yes |
| RJ-45 input ports | 1 |
| S/PDIF in port | Yes |
| Number of HDMI outputs | 8 |
| HDMI in | 8 |
| HDMI version | 2.0 |
| HDMI ports quantity | 16 |
| Video port type | HDMI |
| Features | |
|---|---|
| HDCP | Yes |
| Supported graphics resolutions | 1920 x 1080 (HD 1080), 3840 x 2160, 4096 x 2160 |
| Supported video modes | 1080p, 2160p |
| LED indicators | Yes |
| Heat dissipation | 205 BTU/h |
| HDCP version | 2.2 |
| Maximum operating distance | 7 m |
| Maximum resolution | 4096 x 2160 pixels |
| Maximum refresh rate | 60 Hz |
| Rack mounting | Yes |
| Extended display identification data (EDID) | Yes |
| Consumer Electronics Control (CEC) support | Yes |
| Product colour | Black |
| Power | |
|---|---|
| Power consumption (max) | 60 W |
| AC input voltage | 100 - 240 V |
| Weight & dimensions | |
|---|---|
| Weight | 3.66 kg |
| Height | 43.5 mm |
| Depth | 300 mm |
| Width | 440 mm |
| Packaging content | |
|---|---|
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
|---|---|
| Storage relative humidity (H-H) | 10 - 90% |
| Operating relative humidity (H-H) | 10 - 90% |
| Storage temperature (T-T) | -20 - 70 °C |
| Operating temperature (T-T) | 0 - 45 °C |
| Technical details | |
|---|---|
| Compliance certificates | RoHS |
